75x45mm UHF RFID Pallet Tag

Model FW-PL-7545-U9

Frequency Band

UHF 860-960MHz

Chip Type

NXP UCODE 9 / Alternative Chip Options Available

Request Quote Request Custom Specs

CLICK TO ZOOM

Product Description

The 75x45mm UHF RFID Pallet Tag is a durable long-range RFID tag designed for pallet identification, reusable transport assets, warehouse inventory, logistics tracking, and other supply-chain applications requiring reliable identification at meter-level distances. Its rugged 75 × 45mm construction and high-tack industrial adhesive make it suitable for repeated handling in warehouses, distribution centers, and outdoor logistics environments.

Operating in the 860-960MHz UHF band under EPC Class 1 Gen 2 / ISO/IEC 18000-6C, the tag can be configured with the NXP UCODE 9 RFID IC or other supported chip options according to project requirements. The standard UCODE 9 configuration provides 96-bit EPC memory and 96-bit TID for serialized pallet and asset identification in compatible handheld, fixed-reader, portal, and forklift RFID systems.

Typical read distance can reach approximately 1 to 12 meters under suitable conditions, depending on reader output power, antenna gain and polarization, tag orientation, pallet material, mounting position, and the surrounding environment. For installation directly on metal surfaces, an optional anti-metal backing configuration should be selected and tested on the actual asset before deployment. Custom services include barcode or QR-code printing, logo customization, pre-encoding, data locking, and optional anti-metal configurations.

Technical Specifications

Product Model FW-PL-7545-U9

RFID Chip Type NXP UCODE 9 / Alternative Chip Options Available

Frequency Band UHF 860-960MHz

Dimensions 75mm × 45mm

Material & Craft Ruggedized Thick PET / ABS Shell / High-Tack Industrial Adhesive

IP Protection Rating IP65 Weatherproof

Memory Capacity EPC: 96 bits / TID: 96 bits / User Memory: None

Evaluated Read Range Approx. 1-12m under suitable conditions / Reader, antenna and environment dependent

Customization Options Laser or Inkjet Barcode & QR Code Printing / Custom Logo / Pre-Encoding / Data Locking / Optional Anti-Metal Backing

Deployment Suitability On-Metal Mounting, Asset Tracking & Warehousing, Logistics Tracking

Application Fit

Quick Selection Guide

Use these points to quickly evaluate whether this RFID pallet tag fits your application, installation environment and system requirements.

Best For

Warehouse pallets, reusable transport assets, containers and logistics equipment requiring durable long-range UHF RFID identification for inventory and movement tracking.

Choose This When

Choose this 75x45mm pallet tag when you need a durable adhesive UHF RFID tag with meter-level reading performance for pallets, reusable transport assets or warehouse logistics applications.

Not Ideal For

Not ideal for NFC smartphone applications, short-range access control, disposable item-level packaging, industrial laundry, or direct metal mounting without the optional anti-metal configuration.

Read Range & Installation Note

Typical read distance is approximately 1-12 meters under suitable conditions. Actual performance depends on reader power, antenna placement and polarization, tag orientation, pallet material, mounting position and surrounding objects. For metal surfaces, select the anti-metal version and verify performance on the actual asset before deployment.

Compatibility

UHF 860-960MHz, EPC Class 1 Gen 2 / ISO/IEC 18000-6C with NXP UCODE 9 or supported alternative chip options. Suitable for compatible handheld, fixed, portal and forklift-mounted UHF RFID reader systems used in pallet, warehouse and logistics applications.

Request Custom Specifications for 75x45mm UHF RFID Pallet Tag

Tell us the pallet or logistics asset, mounting location, material, target read range, operating environment and estimated quantity. Our team will review the requirements and recommend a suitable pallet-tag configuration.
