Fongwah Consumables Division

FM4442 / SLE4442 Contact Memory Card

Model FW-CC-4442

Chip Type

FM4442 / SLE4442-Compatible Contact Memory IC

CLICK TO ZOOM

Product Description

The FM4442 / SLE4442 Contact Memory Card is a contact smart card designed for access control, membership systems, loyalty programs, identification, prepaid and other closed-loop card applications. It uses the standard 85.6 × 54mm ID-1 card format and communicates through a physical contact interface rather than RFID or NFC wireless communication.

The card can be supplied with an FM4442 memory IC for SLE4442-compatible applications and provides 256 bytes of EEPROM together with a 3-byte Programmable Security Code (PSC) for controlled write and erase operations. It is intended for systems using compatible contact smart card readers where the chip module must physically contact the reader terminals during operation.

This card is suitable for access credentials, membership cards, loyalty systems, stored-data applications and other identification projects that do not require contactless reading. Custom services include CMYK offset printing, magnetic stripe options, serial numbering, barcode printing, signature panels, hot stamping and other card personalization according to project requirements.

Technical Specifications

Product Model FW-CC-4442

RFID Chip Type FM4442 / SLE4442-Compatible Contact Memory IC

Dimensions 85.6mm × 54mm × 0.84mm

Material & Craft Glossy PVC / Contact IC Module

IP Protection Rating Not Waterproof

Memory Capacity 256-Byte EEPROM / 3-Byte Programmable Security Code (PSC)

Evaluated Read Range Physical Contact Required

Customization Options CMYK Offset Printing / Magnetic Stripe (HiCo/LoCo) / Serial Numbering / Barcode Printing / Signature Panel / Hot Stamping

Deployment Suitability Access Control

Application Fit

Quick Selection Guide

Use these points to quickly evaluate whether this contact smart card fits your application, installation environment and system requirements.

Best For

Access control, membership cards, loyalty programs, prepaid systems and other closed-loop applications requiring a 256-byte contact memory card with security-code-controlled write operations.

Choose This When

Choose this card when your existing system uses an FM4442 or SLE4442-compatible contact memory card and requires 256-byte EEPROM with a 3-byte Programmable Security Code for controlled write and erase operations.

Not Ideal For

Not ideal for contactless access control, NFC smartphone interaction, long-range RFID identification, warehouse inventory scanning, or applications requiring more memory than the 256-byte EEPROM configuration provides.

Read Range & Installation Note

No wireless read range applies. The IC module must make physical electrical contact with a compatible contact smart card reader during operation.

Compatibility

Contact memory card using an FM4442 IC for SLE4442-compatible applications. Requires a compatible physical-contact smart card reader; it is not an HF, NFC or UHF contactless card.

Request Custom Specifications for FM4442 / SLE4442 Contact Memory Card

Tell us the card application, required memory or chip option, printing or personalization needs and estimated quantity. Our team will review the requirements and recommend a suitable card configuration.
