Fongwah Consumables Division

TK4100 125kHz LF RFID Key Fob

Model FW-KF-4100

Frequency Band

LF 125kHz

Chip Type

TK4100 (EM4100 / EM4200-Compatible)

Request Quote Request Custom Specs

CLICK TO ZOOM

Product Description

The TK4100 125kHz LF RFID Key Fob is a compact contactless identification token designed for access control, staff identification, membership systems, attendance management, and other short-range low-frequency RFID applications. Its rugged ABS housing and ultrasonic-welded construction provide a durable everyday format for use with key rings and personal access credentials.

Operating at 125kHz LF, the key fob uses a TK4100 read-only RFID chip compatible with EM4100/EM4200-type applications according to the selected reader system. It provides a factory-programmed 64-bit unique ID for identification and does not provide rewritable user memory, making it suitable for systems where the reader or backend database associates a fixed card ID with a user, door permission, attendance record, or other credential.

Typical reading distance is approximately 1 to 5cm, depending on the reader antenna, reader output, tag orientation, and surrounding environment. The IP67 ABS housing is suitable for everyday access-control use and can be customized with laser-engraved ID numbers, inkjet printing, silk-screen logos, multiple housing colors, and optional key rings.

Technical Specifications

Product Model FW-KF-4100

RFID Chip Type TK4100 (EM4100 / EM4200-Compatible)

Frequency Band LF 125kHz

Dimensions 35.3 x 28 x 6.2 mm / 40.5 x 32 x 4.2 mm (Various housing styles available)

Material & Craft Rugged ABS Shell / Ultrasonic Welding

IP Protection Rating IP67 Waterproof

Memory Capacity 64-bit Unique ID (Read-Only)

Evaluated Read Range Approx. 1-5cm / Reader and antenna dependent

Customization Options Laser-Engraved ID Number / Inkjet Printing / Custom Colors / Silk-Screen Logo / Optional Key Ring

Deployment Suitability Access Control

Application Fit

Quick Selection Guide

Use these points to quickly evaluate whether this RFID key fob fits your application, installation environment and system requirements.

Best For

Door access control, staff identification, attendance systems, membership applications and other short-range 125kHz LF RFID systems using fixed read-only IDs.

Choose This When

Choose this key fob when your access-control system uses 125kHz LF RFID and requires a TK4100 or EM4100/EM4200-compatible read-only credential with a fixed unique ID.

Not Ideal For

Not ideal for NFC smartphone interaction, rewritable memory applications, UHF long-range identification, warehouse inventory scanning, or systems requiring 13.56MHz MIFARE or NTAG credentials.

Read Range & Installation Note

Typical reading distance is approximately 1-5cm. Performance depends on the access-control reader, antenna design, key fob orientation and surrounding materials. Confirm that the target reader supports 125kHz TK4100 or compatible EM4100/EM4200 credentials before ordering.

Compatibility

125kHz LF RFID with TK4100 read-only unique ID, intended for compatible TK4100 and EM4100/EM4200-type access-control reader systems. It is not compatible with 13.56MHz NFC, MIFARE or UHF RFID readers.

Request Custom Specifications for TK4100 125kHz LF RFID Key Fob

Tell us the access or identification application, preferred frequency or chip, printing or personalization needs and estimated quantity. Our team will review the requirements and recommend a suitable credential configuration.

Name *

Company Name *

Business Email *

Phone / WhatsApp

Credential Requirements & Quantity *
