The HF RFID Rectangle Smart Label Series is a 13.56MHz contactless label range designed for asset identification, document management, packaging, inventory tracking, and other short-range HF/NFC applications. Two standard formats are available: a compact 56x18mm label and a larger 86x54mm format. Labels can be produced with coated paper or PET facestock, an etched aluminum antenna, and a self-adhesive backing for roll-format printing, serialization, RFID encoding, and customized labeling projects.
Multiple chip options are available for different reader environments and data requirements. NXP ICODE SLIX is suited to ISO/IEC 15693 systems where longer HF reading distance and document or asset identification are required. NXP NTAG213 supports ISO/IEC 14443 Type A and NFC Forum Type 2 applications, making it suitable for smartphone NFC interaction and short-range product or information access. Fudan FM11RF08S provides a 1KB memory option for ISO/IEC 14443 Type A identification and other closed-loop HF applications.
Actual read distance depends on the selected chip, antenna size, reader and antenna configuration, label orientation, mounting surface, and installation environment. ICODE SLIX configurations are generally better suited to dedicated HF RFID readers, while NTAG213 and FM11RF08S configurations are typically used for closer-range interaction. Custom services include pre-printing, logo and barcode printing, serial numbering, chip selection, RFID data encoding, and custom roll quantities.
