Fongwah Consumables Division

74x50mm ABS RFID Hang Tag (HF NTAG213 / UHF U8 U9 Customizable, 1-8m Read Range)

Model: FW-HT-ABS-05

Frequency Band

Ultra High Frequency (UHF) 860-960 MHz

Chip Type

HF: NTAG213 / UHF: UCODE 8 & UCODE 9 (Customizable)

Request Quote Request Custom Specs

CLICK TO ZOOM

74x50mm ABS RFID Hang Tag (HF NTAG213 / UHF U8 U9 Customizable, 1-8m Read Range)

Product Description

The 74x50mm ABS RFID Hang Tag is a slim, highly versatile tracking transponder designed for flexible deployment across a wide range of industrial and commercial asset environments. Measuring 74mm x 50mm with an ultra-thin 2mm profile and featuring an integrated hanging hole, this tag can be effortlessly attached to non-standard assets, irregular machinery, warehouse racks, or transit containers using zip ties, cables, or screws—offering ultimate adaptation for versatile application scenarios.

Engineered for multi-frequency options, the tag supports High Frequency (HF) embedded with the NTAG213 chip for close-range secure identification, or Ultra High Frequency (UHF) with advanced NXP UCODE 8 (U8) or UCODE 9 (U9) chips based on your specific requirements. The UHF configuration takes full advantage of the large 74x50mm footprint to deliver an impressive, long-range read distance of 1 to 8 meters, making it an excellent all-around choice for asset management, supply chain logistics, and outdoor equipment tracking.

Technical Specifications

Product Model FW-HT-ABS-05

RFID Chip Type HF: NTAG213 / UHF: UCODE 8 & UCODE 9 (Customizable)

Frequency Band Ultra High Frequency (UHF) 860-960 MHz

Dimensions 74mm * 50mm * 2.0mm (With hanging hole)

Material & Craft ABS or PC Housing / Ultrasonic Welding

IP Protection Rating IP67 Waterproof & Dustproof

Memory Capacity HF: 144 Bytes / UHF: EPC 128-bit (Chip dependent)

Evaluated Read Range UHF: 1 - 8 Meters / HF: 1 - 5 cm (Reader dependent)

Customization Options Laser engraved Logo/Serial Number, QR code, Pre-encoding, Color customization

Deployment Suitability Asset Tracking & Warehousing

Request Custom Arrays for 74x50mm ABS RFID Hang Tag (HF NTAG213 / UHF U8 U9 Customizable, 1-8m Read Range)?

Our engineering division will review your target applications and deployment environment parameters to compile an optimized sourcing proposal within 12-24 business hours.
