Fongwah Consumables Division

30mm ABS RFID Disc Tag – Multi-Color

Model FW-ABS-DT-3030

Frequency Band

LF 125kHz, HF 13.56MHz

Chip Type

NXP NTAG213 / NXP ICODE SLIX / HT4168 - Alternative Configurations

Request Quote Request Custom Specs

CLICK TO ZOOM

Product Description

The 30mm ABS RFID Disc Tag – Multi-Color is a compact reusable RFID tag designed for asset identification, equipment labeling, patrol checkpoints, access-related identification, and other applications requiring a small rigid RFID marker. Its 30mm diameter and slim 3mm thickness provide a low-profile installation format, while the smooth coin-style ABS housing is available in multiple colors for visual classification, project coding, or application-specific identification.

This product can be configured with NXP NTAG213, NXP ICODE SLIX, or HT4168 according to the required RFID system. NTAG213 is intended for 13.56MHz HF/NFC applications including compatible NFC-enabled mobile devices, ICODE SLIX is intended for compatible 13.56MHz ISO/IEC 15693 HF RFID systems, and HT4168 is used for compatible 125kHz LF proximity identification systems. These are alternative RFID configurations rather than simultaneous multi-frequency operation.

Actual read distance depends on the selected chip, reader output power, antenna configuration, tag orientation, mounting surface, and surrounding materials. ICODE SLIX can provide a longer HF reading distance with suitable dedicated readers, while NTAG213 is normally used for shorter-range HF/NFC interaction and HT4168 for short-range LF identification. Optional anti-metal isolation and adhesive backing can be specified when required by the installation. Custom services include multi-color housing, laser-engraved UID or logo, logo printing, RFID data encoding, and project-specific configuration.

Technical Specifications

Product Model FW-ABS-DT-3030

RFID Chip Type NXP NTAG213 / NXP ICODE SLIX / HT4168 - Alternative Configurations

Frequency Band LF 125kHz, HF 13.56MHz

Dimensions 30mm Diameter × 3mm Thickness

Material & Craft ABS Housing / Smooth Coin-Style Design / Optional Anti-Metal Isolation Layer

IP Protection Rating IP66 Dust-Tight & Water-Jet Resistant

Memory Capacity NTAG213: 144-byte User Memory / ICODE SLIX: 1024-bit EEPROM (896-bit User Memory) / HT4168: Read-Only Unique ID

Evaluated Read Range ICODE SLIX: approx. 7cm+ / NTAG213: approx. 5cm+ / HT4168: approx. 4cm+ under suitable conditions / Reader, antenna and mounting dependent

Customization Options Multi-Color Housing / Laser-Engraved UID or Logo / Logo Printing / RFID Data Encoding / Optional Adhesive Backing

Deployment Suitability Asset Tracking & Warehousing, Security Patrol & Inspection

Application Fit

Quick Selection Guide

Use these points to quickly evaluate whether this RFID token tag fits your application, installation environment and system requirements.

Best For

Compact asset identification, equipment labeling, patrol checkpoints and visual classification applications requiring a small reusable RFID disc tag with multiple housing colors.

Choose This When

Choose this version when you need a slim 30mm RFID disc without a center mounting hole and want multiple housing colors for visual identification. Select NTAG213 for HF/NFC, ICODE SLIX for ISO/IEC 15693 HF systems, or HT4168 for compatible 125kHz LF systems.

Not Ideal For

Not ideal for long-range UHF inventory scanning, industrial laundry, high-temperature processes, or direct mounting on metal unless a suitable anti-metal configuration is specified.

Read Range & Installation Note

Read distance varies with the selected chip, reader, antenna, mounting surface and tag orientation. ICODE SLIX can provide longer HF reading with suitable dedicated readers, NTAG213 is normally used for shorter-range HF/NFC interaction, and HT4168 is intended for short-range LF proximity identification.

Compatibility

Available with NXP NTAG213 for 13.56MHz HF/NFC, NXP ICODE SLIX for 13.56MHz ISO/IEC 15693 HF systems, or HT4168 for compatible 125kHz LF systems. These are alternative configurations and do not operate simultaneously as a multi-frequency tag.

Request Custom Specifications for 30mm ABS RFID Disc Tag – Multi-Color

Tell us the identification or checkpoint application, mounting method, preferred frequency or chip, required read range and estimated quantity. Our team will review the requirements and recommend a suitable tag configuration.

Name *

Company Name *

Business Email *

Phone / WhatsApp

Tag Requirements & Quantity *
